The 2025 Volvo EX90 arrives with big numbers on the spec sheet: a 107 kWh usable battery, EPA estimates of around 300–310 miles, and Euro WLTP claims as high as roughly 370 miles. But when you put this 6,000‑pound, seven‑seat Swedish skyscraper on wheels through a proper range test, how far does it really go?
Why this range test matters
2025 Volvo EX90 range at a glance
Key 2025 Volvo EX90 range and battery numbers
On paper, every 2025 EX90 in the U.S. uses the same large battery pack and dual‑motor AWD layout. Where range diverges is wheel size, tire spec, and performance tune. Bigger wheels and the Twin Motor Performance calibration take a bite out of efficiency, as you’d expect on a tall three‑row SUV with the aero profile of a modernist apartment block.
2025 Volvo EX90 EPA‑style range expectations
Approximate targets based on early EPA estimates and manufacturer guidance. Always verify the exact number on the window sticker of the vehicle you’re buying.
| Trim | Wheel size | Drivetrain | Battery (usable) | Est. EPA range |
|---|---|---|---|---|
| Twin Motor Plus / Ultra | 20-inch | AWD | 107 kWh | ≈300 miles |
| Twin Motor Plus / Ultra | 21-inch | AWD | 107 kWh | ≈300–310 miles |
| Twin Motor Performance | 20-inch | AWD | 107 kWh | ≈300 miles |
| Twin Motor Performance | 22-inch | AWD | 107 kWh | ≈300 miles |
Wheel size and trim have a modest but noticeable impact on rated range.
EPA vs WLTP vs the real world
How much range do you really get from the EX90?
Independent testing has already given us a fairly coherent picture of how far the EX90 will actually travel on a charge. On balance, it behaves like what it is: a heavy, safe, tech‑laden family bus that’s respectable but not class‑leading on efficiency.
2025 EX90 range: the short summary
What multiple outlets and early owners consistently report
Highway at 70–75 mph
Expect roughly 245–310 miles depending on wheel size, weather, and how obsessively you stick to the right lane.
Mixed city/suburban
In moderate weather, many drivers will see 3.0 mi/kWh or better, translating to roughly 300+ miles per charge.
Cold‑weather reality
In real winter use, multiple owners report 20–30% drops in usable range, with highway blasts in deep cold cutting that further.
In European testing, one outlet managed almost 3.0 miles per kWh in mild conditions, which works out to around 320 miles of real‑world range from the 107 kWh usable pack. U.S. highway tests paint a similar picture: driven at steady interstate speeds, the EX90 tends to land in the mid‑to‑high 200s, with the best cases slightly cracking 300 miles.
Think in energy, not just miles
Highway range tests: 70–75 mph results
Highway testing is where the façade falls away. At 70–75 mph, aero drag is brutal on big boxy SUVs, and the EX90 is no exception. Multiple U.S. outlets have now run instrumented 70–75 mph range tests, and the results tell a consistent story.
- A Twin Motor Performance EX90 on large 21–22 inch wheels has delivered about 250 miles in a controlled 75 mph highway loop before hitting the test cutoff.
- Another publication’s 70 mph highway test saw roughly 310–312 miles out of a non‑Performance EX90, actually beating the EPA estimate by a few miles.
- In a road‑trip‑style 70 mph test with repeated accelerations, passing, and varying terrain, the big Volvo has landed in the mid‑200‑mile zone, in line with what its onboard estimate predicts at 100% charge.
That last detail is important: unlike some rivals that display flattering range numbers at 100% and then quietly erode them, testers have praised the EX90 for honest range prediction. Many see around 250 miles indicated at a full charge on Performance trims with big wheels, and then, lo and behold, that’s roughly what the car will actually do if you trust it down to single digits.
Highway efficiency in context
Winter and cold‑weather range: what owners are seeing
If you live in Minnesota, Vermont, or Alberta, you don’t care much about brochure numbers. You care about what happens at 0°F in a crosswind with two kids, skis, and a golden retriever aboard. The early EX90 owner reports are candid, sometimes brutal, and broadly in line with what we see across large EV SUVs.
Cold‑climate owner anecdotes
- Mountain‑area drivers in Europe have reported consumption climbing above 35–40 kWh/100 km (around 1.6–1.8 mi/kWh) when driving fast in freezing temps and climbing long grades.
- An owner in Vermont has reported a drop from roughly 310 summer miles to around 215 miles at –10°F, and roughly 260 miles at about 20°F, which is a fairly textbook 20–30% winter penalty.
- German Autobahn users cruising at 130–150 km/h in winter report realistic ranges well under 350 km (≈215 miles) between charges.
What the lab tests say
In structured winter comparison tests, the EX90 has fared solidly mid‑pack or worse on efficiency. When driven at around 0°C on mixed roads, it consumed significantly more energy than its WLTP figure suggests, much like most big EVs tested under the same conditions.
The big Volvo does at least fight back with a standard heat pump, heated seats and wheel, and smart thermal management that minimizes waste. But if you’re used to gas SUVs barely noticing the cold, the scale of the hit in an EV can still be a shock the first winter.
Plan for a 30% haircut in deep winter
City, suburban, and family‑duty driving
Put the EX90 back into its natural habitat, school runs, Costco raids, office commutes, and the picture brightens. At lower average speeds with lots of braking opportunities, its regen system and heat pump earn their keep.
What to expect around town
The EX90 is happier at 35 mph than 75 mph
Stop‑and‑go advantage
Frequent slowing lets the EX90 recapture energy via strong regeneration. Use one‑pedal mode in town and you’ll see efficiency improve.
Suburban commuting
On mixed 35–55 mph routes in mild weather, many drivers will see the guess‑o‑meter sit comfortably in the 290–320 mile range from full.
Loaded family duty
Seven passengers, cargo, roof box? Expect a 10–15% hit versus driving solo. Big aero accessories and weight matter more than you think.
If your typical day is 30–60 miles with overnight home charging, the EX90 is effectively a bottomless well. It’s only when you string together long interstate days in bad weather that its mass, frontal area, and wheel choice become a more obvious constraint.
Battery pack, charging speeds, and efficiency
Underneath the EX90 is a large, flat, lithium‑ion pack: 111 kWh gross, 107 kWh usable. That’s in the same neighborhood as an R1S or EQS SUV and bigger than the pack in many two‑row EV crossovers. Volvo has opted for a conservative usable buffer, which should help long‑term battery health.
2025 Volvo EX90 battery and charging specs
Core technical specs that affect real‑world range and road‑trip convenience.
| Item | Specification | What it means for you |
|---|---|---|
| Battery chemistry | Lithium‑ion, 400V architecture | Proven tech; not cutting‑edge 800V, but still quick enough on DC fast chargers. |
| Total / usable capacity | 111 kWh / 107 kWh | Plenty of energy; think of it as a 300‑mile tank when driven reasonably. |
| Max DC charge rate | Up to 250 kW quoted | In testing, peaks nearer 190–200 kW but still adds ~90–100 miles in 15 minutes. |
| 10–80% charge time | ≈30 minutes (ideal conditions) | Plan 25–35 minutes at a good station; longer in cold weather or at crowded sites. |
| Max AC charge | 11 kW (Level 2) | About 10–12 hours for 0–100% at home; overnight top‑ups are easy. |
The EX90’s big battery is paired with genuinely fast DC charging when you can find a strong 250 kW station.
Home charging is your superpower
How the EX90’s range compares to key rivals
Range rarely exists in a vacuum; it’s part of a cross‑shop. If you’re looking at an EX90, chances are the Kia EV9, Rivian R1S, Mercedes EQS SUV, or BMW iX are also on the mood board. When you normalize for test procedures, the EX90 tends to land in the middle of the three‑row pack, better than some, behind the very best.
EX90 vs other large electric SUVs (highway range tests)
Approximate 70–75 mph range results from major U.S. publications for comparable trims. Exact numbers vary by wheel, tire, and weather.
| Model & trim | Battery (usable, approx.) | Rated range | Observed 70–75 mph range | Notes |
|---|---|---|---|---|
| Volvo EX90 Twin Motor Perf. | 107 kWh | ≈300 mi | ≈247–250 mi | Honest range display; big 21–22" wheels hurt aero. |
| Kia EV9 AWD Long Range | ≈95 kWh | ≈280–304 mi | ≈260–270 mi | Slightly better aero; still a big box. |
| Rivian R1S Dual Motor Large | ≈105 kWh | ≈310–340 mi | ≈270–290 mi | Strong highway range when driven gently. |
| BMW iX xDrive50 | ≈105 kWh | ≈324–350 mi | ≈310+ mi | One of the segment’s efficiency standouts. |
The EX90 is competitive, but not a runaway efficiency champ among big luxury EVs.
What you’re trading for range
Real‑world planning tips for EX90 owners
Make the most of your EX90’s range
1. Know your real baseline
Take one relaxed highway trip at 70–75 mph from 100% down to about 10–15% and note miles driven and energy used. That’s your personal baseline, far more useful than any brochure number.
2. Use preconditioning and seat heaters
Pre‑heat the cabin while plugged in, and lean on heated seats and steering wheel so you can lower the HVAC setpoint. That uses far less energy than blasting hot air from a cold battery.
3. Watch your speed and roof accessories
Every 5–10 mph over 70 is a tax on range, especially with a boxy SUV. Roof boxes and bike racks are double jeopardy, aero drag plus extra weight. Remove them when you don’t need them.
4. Favor smaller wheels if range matters
If you’re ordering or choosing between used EX90s, the smaller‑diameter wheels with higher‑profile tires are kinder to efficiency and comfort. The big 22s look great in photos; they’re less great on a long winter drive.
5. Learn the charging curve
Fast chargers are most effective between roughly 10–60% state of charge. On road trips, shorter, more frequent stops in that band can be quicker overall than charging from 5–90% in one go.
6. Keep software up to date
Over‑the‑air updates can materially improve efficiency, charging behavior, and route planning. When shopping used, ask the seller if the car’s software is fully up to date and whether they’ve had any range‑related quirks addressed.
Should you buy a used EX90 if range is your priority?
Range is only one chapter in the EX90 story, but it’s a major one, especially on the used market, where you’re weighing a premium three‑row EV against lower‑cost two‑row models that may go farther on a charge. The good news is that with its large buffer and conservative tuning, the EX90’s battery is engineered for longevity as much as outright spec‑sheet glory.
Why a used EX90 can make sense
- Big 107 kWh usable pack gives you plenty of headroom even after years of normal degradation.
- Standard heat pump and thoughtful thermal management help preserve range in harsh climates.
- Honest range estimation and a calm, predictable driving demeanor make it easy to live with.
- For many families who drive under 200 miles on any given day, it’s functionally indistinguishable from having "infinite" range with home charging.
Questions to ask before you buy
- What’s the typical energy consumption the current owner sees on the highway and in winter?
- Has the vehicle had any battery or charging‑system service, software updates, or recalls?
- Which wheels and tires is the car running, and are they the original spec?
- Can the seller share a recent battery health report or third‑party diagnostic scan?
Shopping through a platform like Recharged can simplify this: every EV comes with a Recharged Score Report that includes verified battery health, fair‑market pricing, and EV‑specialist guidance so you know exactly what you’re getting before you wire a dollar.
How Recharged can help
2025 Volvo EX90 range: FAQ
Frequently asked questions about the EX90’s range
The 2025 Volvo EX90 doesn’t cheat physics. It’s a tall, heavy, deeply safe, exquisitely quiet family hauler that trades a slice of ultimate efficiency for those virtues. Treat it gently and you’ll see real‑world range that flatters the EPA label; treat it like an autobahn grand tourer in sub‑freezing weather and you’ll watch the miles evaporate. The key is matching its honest, mid‑pack efficiency to your actual life. If most of your days are under 200 miles with reliable Level 2 charging, and you value the calm, minimalist Volvo cocoon as much as another 20 miles of range, the EX90’s real‑world numbers may be exactly enough. And if you’re scanning the used market, pairing those numbers with verified battery health and transparent pricing through Recharged can turn this Swedish skyscraper into a surprisingly rational long‑term EV choice.
